Wireless Power Supply Inverter Products
In 2008, SPC Electronics commercialized wireless power supply inverters and has since participated in demonstration tests for dynamic wireless charging of electric vehicles. Through these initiatives, we contribute to the development of wireless power supply systems as next-generation infrastructure for automobiles, railways, and personal mobility solutions.
Wireless Power Supply Inverters
Wireless Power Supply Inverters
- High-efficiency wireless power supply inverter with proprietary digital PWM control and SiC devices
- We have commercialized a high-frequency inverter for use in wireless power supply demonstration tests.
Features
- High-efficiency, high-power wireless power supply enabled by proprietary digital PWM control and SiC devices
- Four 11.1 kW inverters compliant with SAE standard WPT3 support individual power transfer to multiple vehicles and simultaneous power transfer to multiple coils on a single vehicle
- Circuit optimization enables power transfer over a maximum cable length of 30 m, supporting flexible installation layouts
Key performance
横にスクロール出来ます
| Item | Key performance |
|---|---|
| Supported standard | SAE : WPT3 |
| Size | W800mm×D500mm×H1,800mm |
| Frequency | 85kHｚ（79kHz～90kHz） |
| Output power | 11.1kW×4 (Individual / simultaneous power transfer) |
| Power transfer efficiency | 85% or higher |
| Input power supply | Three-phase 200 V (55 kVA) |
| Cable length | Max. 30 m |
| Detection function | Vehicle detection function included |
